8" Indoor Infrared Thermometer Body Temperature Binocular Face Recognition Camera Measurement Android Wifi Digital Signage
Quick details:
1. 8inch IPS panel
2. Binocular face recognition camera inbuilt
3. Infrared temperature sensor inbuilt
4. Support 16 multi language like Chinese, English,Spanish, French, Germany etc.
5. English software to be provided for free
6. Can work standalone, local area network or with cloud server
7. To be used with Entrance Barrier Gate face reader and Door Entry System
8. We have floor stand or table stand on option, also can be installed on the wall
9. IC, ID card reader inbuilt
Description:
The temperature measuring device should be used in a room with a room temperature between 10 ℃-40℃. Do not install the
temperature measuring device under the vent, and ensure that there is no heating source within 3 meters.
The 8inch can be used standalone or through internet, record face first, next time when you stand in front, it will speak your name and test temperature automatically, also will test temperature for anybody who stand in front, if connect to a relay gate, it will give pass or stop for person who has data record inside, also an xls file can be downloaded by administrator to check what time they test temperature and if their temperature is normal.
Temperature degree can be set in the background, current the default value is 37.3, also the machine can speak out normal temperature or abnormal temperature, for abnormal one, it will alarm as well. Besides, it supports 16 multi languages voice temperature notification.
Also it has an IC/ID card reader, if somebody do not want to record face but just use IC/ID card for log in and test temperature, this is also ok, if you use the card reader, you need to install the software which support local area network and cloud server.
We have floor stand or table stand on option, also it can be with a wall-mount bracket to hang on the wall.
Specification:
| Chipset | RK3288 |
| System | Android operation system |
| RAM | 8G EMMC |
| Image sensor | 1/2.7" CMOS |
| Lens | 4.5mm |
| Camera Parameters |
| Camera | Binocular camera supports live detection |
| Effective pixel | 2Mega pixel,1280*800 |
| Min. lux | Color 0.01Lux @F1.2(ICR);B/W 0.001Lux @F1.2 |
| SNR | ≥50db(AGC OFF) |
| WDR | ≥80db |
| Face Recognition |
| Height | 1.2-2.2 M, angle adjustable |
| Distance | 0.5-2 Meters |
| View angle | Vertical ±40 degree |
| Reco. Time | <500ms |
| Temperature |
| Range | 30-45(℃) |
| Accuracy | ±0.3(℃) |
| Distance | 0.3-0.8m |
| Response time | <300ms |
| Interface |
| Internet interface | RJ45 10M/100M Ethernet |
| Weigand port | Support input/output 26 and 34 |
| Alarm output | 1channel relay output |
| USB port | 1USB port (Can be connected to ID identifier) |
| General |
| Power input | DC 12V/3A |
| Power consumption | 20W(MAX) |
| Working temperature | 0℃ ~ +50℃ |
| Humidity | 5~90%, no condense |
| Dimension | 123.5(W) * 84(H) *361.3(L)mm |
| Weight | 2.1 kg |
| Column aperture | 33mm |
Application:
Product Tags:
|
|
Face Recognition Floor Standing Digital Signage Temperature Measuring Devices Images
|
